Description
Loop Telecom’s 1-channel V.35/EIA530/RS232/X.21 plug-in cards are designed for the mini slot of Loop- O9550 series. It allows multiplexing of N x 64 kbps data to multiples of DS0 time slots onto a digital network. An LED on the front panel of the Loop-O9550 provides status indicators.
- 1-channel DTE plug-in cards for mini slot (V.35, EIA530, X.21, RS232)
- Maximum date rate
- V.35, EIA530 and X.21 N x 56 or 64 kbps, N = 1 to 32
- RS232: N x 56 or 64 kbps, N = 1 to 2
- Mapping to any sequential time slots
- Remote diagnostics
